ARKTEK H610M Motherboard LGA1700 Micro-ATX | Intel H610 Chipset | DDR4
The ARKTEK H610M is a compact Micro-ATX motherboard built on Intels H610 chipset, offering solid compatibility with 12th, 13th, and 14th Gen Intel Core processors. Designed for mainstream system builds and office deployments, it supports dual-channel DDR4 memory and includes essential expansion and connectivity options for everyday performance.
Specifications
Model: AK-H610M EG
Chipset: Intel H610
Socket: LGA 1700
Processor Support: Intel 12th/13th/14th Gen Core i9/i7/i5/i3, Pentium Gold, Celeron
Memory: 2 × DDR4 DIMM slots, up to 64 GB (21333200 MHz XMP)
Graphics: Integrated Intel HD Graphics support (HDMI, VGA, DP)
Storage: 3 × SATA 3.0 ports, 1 × M.2 (NVMe), 1 × M.2 Wi-Fi/Bluetooth
LAN: Realtek 8111H Gigabit Ethernet with Wake-on-LAN and PXE
Audio: HD Audio 3-in-1 port
Expansion Slots: 1 × PCI-E x16, 1 × PCI-E x1
USB: 2 × USB 3.0, 2 × USB 2.0 (plus internal headers)
Internal Connectors: F_USB, USB 3.0, F_AUDIO, J_SPK, JCMOS, CPU_FAN, SYS_FAN
Form Factor: Micro-ATX (22 × 18 cm)
Accessories: SATA cable, I/O shield, manual, driver CD
Operating System Support: Windows 7/8/8.1/10 (x64)
Mounting: 6 points
Intended Use:
OEM / System Integrator grade board for entry-level desktops, office PCs, education, and general-purpose builds.
Warranty: 12 Months
