TBYTE H410 10TH GEN LGA1200 MOTHERBOARD - H410
Model: H410
Chipset: Intel H410
CPU Socket : Support 10th Generation Comet Lake-S Corei9 / Corei7 / Corei5
Corei3 / Pentium / Celeron series processors for LGA 1200 socket
Memory Support: Dual Channel DDR4DDR4 2400/2666/2933MHz
Dimm: 2 x Memory Slots (Max. up to 32GB each)
SATA: 4 X SATA3.0 6Gb/s M.2 (PCI-E 3.0 X4 NVME SSD)SSD & SATA3.0 SSD Supports INTEL Optane
LAN: Realtek 100M/1000Mbps
AUDIO: 3 x 3.5mm
Display
1 x VGA
1 x HDMI
USB Expansion Port : 2 x USB2.0 pinheader supports additional 4 USB 2.0 ports
1 X USB3.0 pinheader supports additional 2xUSB 3.0ports , 2 x USB3.0 I/O Interface ;2 USB2.0 I/O Interface
Form Actor: M-ATX 18 x 22cm
Power : 24+8
Other interface : 1 x PS/2
1 x RJ45
1 x M.2,support SATA/PCI-E
PCI-E: 1 X PCI Express x16
FEATURE:
Gigabit LAN optional
All solid capacitor optional
Full range of alloy heat dissipation armor
4.LED audio block noise reduction isolation line 5.8 Phase Enhanced digital power supply
