Switch Gigabit Poe 4Port PoE + 1 Upl - 4 PORT 10/100/1000 POE Switch - TXE038
5-Port 10/100/1000Mbps Unmanaged PoE Switch(4-Port PoE)
Model Name: TXE038
Chipset: MT7530DU+IP804A
Standards and Protocols: IEEE802.3, IEEE802.3i,IEEE 802.3u,IEEE802.3ab,IEEE802.3x, IEEE802.3az,IEEE802.1q, IEEE802.3at,IEEE802.3af
Interface: 5 x 10/100Mbps Auto-Negotiation ports
Network Media:10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
Transfer Method: Store-and-Forward
MAC Address Table: 2K
Switching Capacity: 10Gbps
Packet Forwarding Rate: 7.44Mpps
PoE Ports(RJ45): 4 x PoE ports compliant with 802.3at/af
Power Pin Assignment: 1/2(+),3/6(-)
PoE Budget: 60W
Indicators
Per Device: Power,VLAN
Per Port: Link/Activity
Power Supply: DC 52V,1.25A External Power
Power Consumption: Maximum(PoE on): 63W (220V/50Hz)
Dimensions ( W x D x H ): 123 x 70 x 23mm
Environment: Operating Temperature: 0?~45?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
