- Camera
- Image Sensor1 MP CMOS image sensor
- Max. Resolution1296 (H) × 732 (V)
- Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time1/25 (1/30) s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens TypeField of view: 70.9°(3.6 mm), 92°(2.8 mm), 56.7°(6 mm)
- Lens MountM12
- Image
- Frame Rate720p@25fps/720p@30fps
- SNR>62 dB
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- DimensionF 89.9 mm × 70.1 mm (3.54" × 2.76")
- 250 g (0.55 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
- Power Supply12 V DC±15%
- ConsumptionMax. 4 W
- IR RangeUp to 20 m
