FEATURES:
- AMD AM4 socket: Ready for Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
- A520 chipset with dual channel DDR4 memory support
- DisplayPort, HDMI, and VGA support
- Comprehensive cooling: Large VRM heatsink, PCH heatsink, Fan Xpert 2+
- Made for online gaming: 802.11ac Wi-Fi, TUF LANGuard and TurboLAN technology
- Aura Sync RGB: Onboard RGB headers and addressable Gen 2 headers for RGB LED strips, easily synced with Aura Sync-capable hardware
SPECIFICATIONS:
- Socket: AM4
- CPU: AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
- Chipset: A520
- DDR4 Memory: DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHz
- Memory Channel: Dual
- DIMM Slots: 4
- Max Memory (GB): 128GB
- PCI-E 3.0 x16: 1
- PCI-E 3.0 x1: 2
- M.2 Slot: 1
- SATA 6G: 4
- RAID: 0/1/10
- LAN: Realtek 1Gb Ethernet/ TUF LANGuard
- Wireless and Bluetooth: Realtek Wi-Fi 5 8821CE
- USB 3.2 ports (Front): 2(Gen 1, Type A)
- USB 3.2 ports (Rear): 4(Gen 1, Type A)
- USB 2.0 ports (Front): 3
- USB 2.0 ports (Rear): 2
- Audio ports (Rear): Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC
- HDMI: 1
- Display Port: 1
- VGA: 1
- DirectX: 12
- Form Factor: mATX
- Operating System: Support for Windows® 10 64-bit
WHATS IN THE BOX:
- Asus TUF Gaming A520M-PLUS WiFi AM4 M-ATX Gaming Motherboard Black x1
- SATA Cables x2
- I/O Shield x1
- M.2 SSD Screw Package x1
- Asus Wi-Fi Antenna x1
- TUF gaming sticker x1
- User Manual x1
